    IPX3 IPX4 Oscillating Tube Test Device For Ingress Protection Test

    Ask Lasest Price
    Brand Name : HeJin
    Model Number : HH0802
    Certification : Calibration Certificate(cost additional)
    Price : Negotiatable
    Payment Terms : L/C, T/T
    Supply Ability : 15 set per month
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    IPX3 IPX4 Oscillating Tube Test Device For Ingress Protection Test

    IPX3 IPX4 Oscillating Tube Test Device Used For Ingress Protection Test


    Standard of IPX3 IPX4 Oscillating Tube :

    IEC60529 degree of protection provided by enclosures (IP Code), Figure 4 – Test device to verify protection against spraying and splashing water; second characteristic numerals 3 and 4 (oscillating tube);


    Application of IPX3 IPX4 Oscillating Tube:

    IPX3 IPX4 Oscillating Tube Test Device is intended for determining the degree of protection, against ingress of water IPX3 and IPX4.


    Feature of IPX3 IPX4 Oscillating Tube:

    1. The complete set of equipment consists of oscillating tube, turntable, and control cabinet.

    2. Height of oscillating mechanism can be adjusted.

    3. Allows configuration of oscillating tubes of different radii.

    4. The oscillating tube can spray ±60° from vertical for IPX3 testing and spray±180° from vertical for IPX4 testing.

    5. The water flow rate is adjustable.


    Parameter of IPX3 IPX4 Oscillating Tube:

    ItemParameters
    Input powerSingle-phase AC240V,50Hz
    Water supply

    Water flow rate>10L/min±5% clean water without inclusion.

    This device is equipped with clean water filtration unit

    Control and operationPLC intelligent control, 7 inch color touch screen operation
    The size of the oscillating tubeR200 , R400, R600, R800, R1000, R1200, R1400, R1600mm, stainless steel
    Needle holeΦ0.4mm
    Included angle of two holesIPX3: 120°; IPX4: 180°
    Pendulum angleIPX3: 120°(±60°); IPX4: 350°(±175°)
    Raining speed

    IPX3: 4 s/time(2×120°);

    IPX4: 12 s/time(2×350°);

    Water flow1-10L/min adjustable
    Testing time0.01s~99hours 59min, can be preset
    TurntableDiameter: Φ600mm; Rotate speed:1r/min, Can be paused at four aspects, Load bearing≤100kg electrical equipment
    Site requirementsDedicated IP waterproof test room, The ground should be flat with illumination. 10A waterproof leakage switch(or socket)used for equipment. With good function of inflow and drainage. Ground installation
