    IEC60112 CTI PTI Flammability Testing Equipment PLC Control

    IEC60112 CTI And PTI Flammability Testing Equipment PLC Control


    Standard:

    IEC60112-2009 Method for the determination of the proof and the comparative tracking indices of solid insulating materials.

    It specifies the method of test for the determination of the proof and comparative tracking indices of solid insulating materials on pieces taken from parts of equipment and on plaques of material using alternating voltages. Flammability Testing Equipment


    comparative tracking index

    CTI

    numerical value of the maximum voltage at which five test specimens withstand the test period for 50 drops without tracking failure and without a persistent flame occurring and including also a statement relating to the behaviour of the material when tested using 100 drops


    proof tracking index

    PTI

    numerical value of the proof voltage in volts at which five test specimens withstand the test period for 50 drops without tracking failure and without a persistent flame occurring


    Parameter:

    ParametersModelLT-3(0.5m³) (Touch screen)
    Working voltage220V/50Hz, 1KVA
    Control operation modePLC control, 7 inch color touch screen operation, with infrared remote control
    Testing voltage0~600V adjustable, precision 1.5%
    Timing device9999X0.1S
    ElectrodeMaterial: Platinum electrode and brass connecting rod
    Size: (5±0.1)×(2±0.1)×(≥12)mm, 30°slant, Tip rounding:R0.1mm
    Relative position of electrodeIncluded angle: 60°±5°, distance is 4±0.1mm
    Electrode pressure1.00N±0.05N, Touch screen display
    Dripping liquidThe interval time of dropping liquid: 30±5S, digital display, can be preset
    Height: 35±5mm
    The number of drips:0-9999 times, can be preset, the volume size of the dripping liquid is controlled by the imported micro pump within 50 ~ 45 drips /cm³
    Test liquid resistanceA liquid 0.1%NH4Cl, 3.95±0.05Ωm, B liquid 1.7±0.05Ωm
    Time-delay circuit2±0.1S (in 0.5A or larger current)
    Short-circuit pressure drop1±0.1A 1%, pressure drop 8% MAX
    Wind speed0.2m/s. Flammability Testing Equipment
    Environmental requirement0~40℃, relative humidity≤80%, in the place of no obvious vibration and corrosive gas
    Dimensions and weightWDH=1100×550×1200 mm, about 130kg
