    HH0811 300KG 150L Temperature And Humidity Test Chamber

    Ask Lasest Price
    Brand Name : HeJin
    Model Number : HH0811
    Certification : calibration certificate (cost additional)
    Price : Negotiatable
    Payment Terms : L/C, T/T
    Supply Ability : 10 set /month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    HH0811 300KG 150L Temperature And Humidity Test Chamber

    Plug Socket Test Equipment Temperature And Humidity Chamber For Resistance To Humidity With 150L Working Chamber


    Standard:

    IEC 60884-1 ‘Plugs and socket-outlets for household and similar purposes –Part 1: General requirements’ clause 16.1, clause 16.3

    IEC 60669-1 ‘Switches for household and similar fixed electrical installations –Part 1: General requirements’ clause 15.1, clause 15.3

    The test device is designed and manufactured according to IEC 60068-2, Test methods-test A: cold, test B: dry heat, test Cab: damp heat, steady state, test Db: damp heat, cyclic.


    Parameter:

    Product NameProgrammable Temperature Humidity Chamber
    Volume, size and weight
    Working Volume150L (can be customized)
    Inner sizeW600mm × H600mm × D460mm
    Outer sizeW900mm × H1800mm × D1500mm
    Weight300KG
    Temperature controller7-inch programmable controller (touch screen)
    Performance
    Temperature range-40℃~+150℃
    Humidity range20-98%HR
    Temperature deviation≤±2℃(without load, under constant state)
    Temperature uniformity≤±2℃(without load, under constant state)
    Temperature fluctuation±0.5℃(without load, under constant state)
    Humidity deviation± 3% RH (above 75%); ± 5% RH (below 75%)
    Heating rate3-5℃/ min
    Cooling rate0.7-1℃/ min
    Structure
    Outer material3A cold-rolled steel sheet with electrostatic double-sided plastic spray, color is pearl white
    Inner wall materialSUS304# mirror stainless steel plate
    Insulation materials100mm rigid polyurethane foam
    Observation windowSet on the door of the test chamber, size: about 300 × 460mm (width × height), coated with frost-proof insulating glass
    Pin holes1 hole of Φ50mm, on the left side of chamber
    Protection system

    1 Chamber:

    1) Independent over-temperature protector

    2) Fan overheating protection

    2 Cooling System:

    1) Compressor overpressure

    2) Compressor overcurrent

    3) Compressor overheating

    4) Exhaust temperature protection

    3 Power system:

    1) Power phase loss and phase sequence error protection

    2) Leakage protection

    3) Heater over-temperature protection

    4) Overcurrent protection such as heater short circuit

    4 Others: Test chamber shell ground protection
