High Current Arc Ignition Tester Arc Ignition Speed 40
Times/Minute Flammability Testing Equipment
Product Introduction
HAI-1 High Current Arc Ignition Tester is a professional
Flammability Testing Equipment created by the original
manufacturer. It strictly follows international standards and
provides enterprises with reliable material flame retardant
performance testing support with efficient and accurate testing
capabilities, helping enterprises to strictly control product
quality, ensure product safety when facing fire sources, and
protect the safety of users' lives and property.
Standard:
IEC 60950-1 Information technology equipment - Safety - Part 1:
General requirements.
IEC60947-1 Low-voltage switchgear and controlgear - Part 1: General
rules.
IEC60730-1 Automatic electrical controls -Part 1: General
requirements.
Product Use:
Automotive parts: Detect arc resistance of wiring harnesses and
connectors to avoid driving safety hazards.
Electronic appliances: Evaluate the flame retardancy of insulation
materials such as switches and sockets under high current.
Industrial materials: Test the flame retardancy level of
engineering plastics and insulation coatings to ensure compliance.
Feature:
The arc striking speed can reach 40 times/minute, which greatly
improves the test efficiency and can quickly complete the test of a
large number of samples to meet the company's efficient testing
needs.
The arc strike time 0-9999 can be preset, the electrode separation
speed is 254±25mm/s, and the test parameters are precisely
controlled to ensure that each test result is accurate and
consistent.
It complies with international standards such as IEC 60950-1,
IEC60947-1, and IEC730-1. The test results are authoritative and
provide credibility for enterprises.
It adopts electrical control and button operation mode, which is
simple and intuitive to operate. Novices can also quickly master it
and easily carry out testing work.
The working voltage is 220V/50Hz, equipped with an independent
exhaust system to effectively exhaust harmful gases and ensure a
safe operating environment. The electrodes are made of high-quality
copper and stainless steel materials to ensure long-term stable and
reliable use.
Parameters:
Working voltage | 220V/50Hz(Flammability Testing Equipment) |
Control operation mode | Electrical control, button operation |
Arc strike current and power factor | When the power factor is 0.5, the current is 33A±0.5A |
Arc strike speed | 40 times/min |
Electrode separation velocity | 254±25㎜/s |
Arc strike times | 0-9999 can be preset |
Electrode material | Static electrode—copper,dia.Ф3.5mm (Ф3.2)×152mm,top bevel angle 30° Moving electrode—stainless steel,diaФ3.5mm(Ф3.2)×152mm, top cone
angle 60° |
Electrode included angle | Form 45° with level,electrode head radius of curvature 0.1mm |
Test procedure | Automatic control, independent exhaust |
Lighting | Equip with lighting in the test chamber, with control |
Test chamber and dimension | LWH:800×700×1600mm,300kg |
Product Details:
After-sales service:
Worry-free warranty: 1 year warranty for the whole machine,
lifelong maintenance of core components.
Technical support: Remote guidance installation, operation training
and annual calibration services.
Quick response: Provide solutions within 24 hours.
