Power 5KW Battery Pack Helium Leak Detector with Suction Gun HJ124
Leak Testing Equipment
Product Overview:
This equipment is mainly used for airtightness testing of PACK
battery packs, including evacuation, helium filling, pressure and
concentration detection, as well as helium leak detection using a
suction gun.
Product Working Principle:
After a certain pressure of helium is filled into the workpiece, a
pressure difference is formed between the inside and outside of the
workpiece. If there is a leak in the outer shell of the workpiece,
the helium inside the workpiece will leak to the outer surface of
the workpiece. The operator will use a suction gun to scan the
outer surface of the workpiece. The leak detector can accurately
and quickly determine the leakage situation of the workpiece, and
the system will give an alarm prompt if there is a leakage.
Product Features:
Automatic Gas Concentration Monitoring: The system has automatic
helium concentration monitoring functions as well as concentration
alarm features.
Integrated Commissioning Technical Services: Hejin can provide
commissioning services for connecting the recovery system with the
customer's existing helium leak detection equipment.
Product Parameters:
| Size | ≤1000 (L) × 800 (W) × 1200 (H) mm |
| Power | 5KW |
| Energy Consumption | AC 220V, 50 Hz, 3-phase 5-wire system, maximum power 5KW |
| Package Filling Pressure | 2~2.5 kpa |
| Package Evacuation Pressure | -2~-3 kpa |
| Alarm Leak Rate | 1.44E-4 mbar.l/s |
| Test Mode | Suction Gun Mode |
| Concentration Monitoring | Equipped with an automatic online real-time helium concentration
monitor, capable of automatically controlling helium filling,
accuracy ±2% |
| Cycle Time | ≤2 minutes (excluding manual scanning time with suction gun) |
| Connectors | 2 connectors (1 for hard package, 1 for soft package) |
Product Image:
Our advantage service:
We possess a professional R&D and design team that leverages
their proficient skills and innovative thinking to provide
customers with uniquely crafted product solutions. If you have any
novel ideas or unique needs for a product, please feel free to
share them with us, and we will carefully craft a one-of-a-kind
product design based on your creativity and expectations, meeting
all your aspirations.
Technical support:
All our workers are experienced and skilled.
After sale service:
Our professional working team and outstanding sales team are
committed to providing our clients with products worldwide and
guaranteeing fast and efficient after-sales services to meet
various needs.
