Total Power 75~400kW Vacuum Annealing Furnace HJ-VF009 Vacuum
Furnace Load Capacity 15000kg
Application Range with Vacuum Furnace:
The vacuum annealing furnace is specifically designed for small
silicon steel laminated cores. It utilizes vacuum annealing
technology to eliminate cold working stress in materials, restore
internal grain structure, remove impurities from the core surface,
and significantly enhance the magnetic conductivity of the core.
Product Features with Vacuum Furnace:
This product boasts a uniquely crafted design for its metal heaters
and metal heat insulation screens, effectively addressing the
issues of thermal deformation and damage caused by high
temperatures. Additionally, the incorporated constant-rate cooling
control system ensures precise temperature control and cooling
during the annealing process of special materials, thereby
guaranteeing the stability and reliability of product quality.
Product Parameters with Vacuum Furnace:
| Furnace Type | Effective Chamber Size (mm) | Rated Furnace Temperature (℃) | Furnace Load Capacity (kg) | Total Power (kW) |
| Vertical | Φ2200×1800×2000 | 900 | 15000 | 320 |
| Φ1200×1200 | 1200 | 1000 | 220 |
| Φ1000×1000 | 1200 | 500 | 180 |
| Φ800×800 | 1200 | 300 | 150 |
| Horizontal | Φ2600×1200×1200 | 900 | 6000 | 200 |
| Φ2600×1000×1200 | 900 | 5000 | 180 |
| Φ2000×800×800 | 1600 | 1000 | 400 |
| Φ1000×600×600 | 900 | 600 | 100 |
| Φ800×500×500 | 900 | 400 | 80 |
| Φ600×400×400 | 1200 | 200 | 95 |
| Φ500×300×300 | 1200 | 100 | 75 |
Product Image with Vacuum Furnace:
Our advantage service:
We have our own developing and designing team, which ensure our own
technological and innovative products for customers.
For any customers who have new idea about some products, just let
us know, we can according to your idea provide a unique design of
the products.
Technical support:
All our workers are experienced and skilled.
After sale service:
Our working team and sales teams can guarantee a fast and high
efficiency after-sale service for our product sold to everywhere of
the global.
